Disk shelves & storage media for NetApp FAS, AFF & ASA systems

Disk shelves and storage media : hero [j-ovl5] - Image [10-w62b]

Key Benefits

Disk shelves and storage media specifically designed for NetApp^® AFF, ASA, AFX, and FAS systems help deliver the performance, resiliency, and flexibility your digital transformation needs.

Gain performance and capacity at every level

Explore a full range of disk shelves and storage media (SSD and HDD) to support your diverse business and application demands. These disk shelves are supported on AFF, ASA, AFX, and FAS systems.

Select model

Disk shelves and storage media - Tab 1 Image [n-ho7e]

Gain flexibility

Leverage NetApp drives and disk shelves across the ONTAP^® portfolio.

Optimize for performance and capacity

Choose the media to optimize your storage for performance and capacity, leveraging SSD and HDD.

Strengthen security

Enhance physical data security. Prevent unauthorized data access.


	NX224	NS224	DS224C	DS212C	DS460C
Main Specifications
Rack units	2U	2U	2U	2U	4U
Drives per enclosure	24	24	24	12	60
Drives per rack unit	12	12	12	6	15
Drive form factor	2.5" small form factor	2.5" small form factor	2.5" small form factor	3.5" large form factor	3.5" large form factor
Drive carrier	Single drive	Single drive	Single drive	Single drive	Single drive
High-capacity disk drives	N/A	N/A	N/A	4TB, 8TB, 10TB, 16TB, 22TB at 7.2K RPM	4TB, 8TB, 10TB, 16TB, 22TB at 7.2K RPM
Performance disk drives	N/A	N/A	900GB, 1.2TB and 1.8TB at 10K RPM	N/A	N/A
Self-encrypting drives^[1]	AES-256 self-encrypting (SED) NVMe SSDs - 7 .6TB, 15.3TB, 30.6TB	AES-256 self-encrypting (SED) NVMe SSDs - 1.9TB, 3.8TB ,7 .6TB , 15.3TB, 30.6TB AES-256 FIPS 140-2 compliant NVMe SSD 3.8TB, 15.3TB, 30.7TB	900GB and 1.8TB at 10K RPM, 800GB and 3.8TB SSD, 800GB SSD + 1.8TB at 10K RPM AES-256, FIPS 140-2 compliant	10TB at 7.2K RPM AES-256, FIPS 140-2 compliant	10TB at 7.2K RPM AES-256, FIPS 140-2 compliant
Solid state drives (full and mixed shelf)	N/A	1.9TB non-SED NVMe SSD, 3.8TB non-SED NVMe SSD, 15.3TB, 30.7TB, 61.4TB	960GB, 3.8TB, 15.3TB, 30TB, 960GB + 1.8TB, 7.6TB	960GB + 4TB, 960GB + 8TB, 960GB + 10TB, 960GB, 960GB + 22TB	960GB + 4TB, 960GB + 8TB, 960GB + 10TB, 960GB, 960GB + 22TB
Controller Support	AFX A1K	AFF A1K, A90, A70, A50, A30, A20, A900, A800, A400, A250. AFF C80, C60, C30, C800, C400, C250. ASA A1K, A90, A70, A50, A30, A20, A900, A800, A400, A250. ASA C30, C800, C400, C250. FAS90, FAS70	AFF A900, AFF A800, AFF A400, AFF A250, AFF A150, FAS90, FAS70, FAS50, FAS9500, FAS8700, FAS8300, FAS2820, FAS2700	FAS90, FAS70, FAS50, FAS9500, FAS8700, FAS8300, FAS2820, FAS2700	FAS90, FAS70, FAS50, FAS9500, FAS8700, FAS8300, FAS2820, FAS2700
Shelf I/O modules	Dual NVMe Shelf Modules (16 x 100GbE connections)	Dual NSM modules (Ethernet Connections)	Dual IOM12 modules	Dual IOM12 modules	Dual IOM12 modules
Optical SAS support	N/A	N/A	✓	✓	✓
Power supply/cooling fans	Dual, hot-pluggable, integrated power supply/fan assemblies	Dual, hot-pluggable, integrated power supply/fan assemblies	Dual, hot-pluggable, integrated power supply/fan assemblies	Dual, hot-pluggable, integrated power supply/fan assemblies	Dual, hot-pluggable power supply; independent fan assemblies
AC input power voltage (autoranging, VRMS)	200–240V	100–120V or 200–240V	100–120V or 200–240V	100–120V or 200–240V	200-240V
AC input power frequency	50–60 Hz	50–60 Hz	50–60 Hz	50–60 Hz	50–60 Hz
Weight—fully loaded	60.1 lbs (27.3 kg)	62.2 lbs (28.2 kg)	53.8 lbs (24.4 kg)	60lbs (27.2 kg)	246.9 lbs (112 kg)
Dimensions	Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 20 in. (50.8 cm)	Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm)	Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm)	Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm)	Height: 7 in. (17.8 cm) Width: 19 in. (48.3 cm) Depth: 36 in. (91.4 cm)
Clearance dimensions	Front and Rear—cooling: 6 in. (15.3 cm) Front—maintenance: 7.9 in. (20 cm) and 24 in. (61 cm). Rear— maintenance: 17 in. (143 cm).	Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm)	Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm)	Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm)	Front—cooling: 6 in. (15.3 cm) Front—maintenance: 30 in. (76 cm) Rear—cooling: 6 in. (15.3 cm) Rear—maintenance: 20 in. (50.8 cm)
Operating acoustic noise	7.7 bels LwAd (2 NSMs)	6.4 bels LwAd (2 PCMs)	6.9 bels LwAd (2 PCMs)	6.3 bels LwAd (2 PCMs)	7.2 bels LwAd (2 PCMs)
Temperature	Operating: 50°F to 95°F (10°C to 35°C) Nonoperating: –40°F to 158°F (–40°C to 70°C)	Operating: 50° F to 104° F (10° C to 40° C) Nonoperating: –40° F to 158° F (–40° C to 70° C)
Relative humidity	Operating: 8% to 80% noncondensing; Nonoperating: 10 to 95% noncondensing	Operating: 20% to 80% noncondensing; Nonoperating: 10 to 95% noncondensing
Altitude	Operating: 0 to 3,000 ft @ 95°F (0 to 914 m @ 35°C); 0 to 10,000 ft @ 82°F (0 to 3,048 m @ 28°C) Nonoperating: Up to 40,000 ft (–305 to 12,192 m) in an unconditioned airplane cargo bay.	Operating: 0 to 10,000 ft (0 to 3,045 m) Nonoperating: –1,000 to 40,000 ft (–305 to 12,192 m)
